MP-500 (500Kg/per day) – Addfield Medical Waste Incinerator

The MP-500 is a pathological and medical waste incinerator, one of our most popular solutions for disposing of mixed medical waste across many countries. Regularly chosen by international aid agencies and Government bodies for installation at hospitals, clinics, research centres, vaccination centres and other large clinical waste facilities.

A compact large medical incinerator that is able to safely dispose of a wide range of medical and clinical waste including, pharmaceutical, biological and high moisture materials.

A compact medical incinerator, the MP-500 includes its secondary chamber within its thick steel outer-shell, combined with 180mm of advanced insulation ensure that the MP-500 delivers outstanding results whilst being completely safe to operate compared to inferior machines which lose heat through the process.

Highly efficient in operation the MP-500 medical incinerator requires up to 40% less fuel to operate due to its advanced construction and insulation including a triple-layered brick-based refractory made up of a thick insulation board, insulation brick a followed by an Alumina Infused outer layer of Thermal bricks that reflect the heat back into the chamber whilst maintaining the heat throughout the process.

Hot Hearth Medical Incinerator

Having a total of four burners the MP-500 Medical Incinerator benefits from a Hot Hearth system which direct the heat underneath the primary chamber delivering 360° heating. Removing any cool spots and enabling the destruction of high moisture organic waste safely.

A front-loading medical incinerator the can safely be reloaded through the incineration process to enable the disposal of higher amounts of medical waste than a top loading alternative.

The MP-500 machine is equipped with a 1.13m³ chamber which is ideal for loading up to 500kg of waste at a time. Designed to handle a wide variety of waste, it is specifically competent when dealing with Category 2, 3 and 4 types or those less than <3000Kcal and red bag waste.

MP-300 (300Kg/per day) – Addfield Medical Incinerator

The MP-300 Medical Incinerator is one of our most popular solutions for disposing of mixed medical waste across many countries. Regularly chosen by international aid agencies and Government bodies for installation at hospitals, primary medical services, clinics, research centres, private surgeries, vaccination centres and other clinical waste facilities.

A compact medium-sized medical incinerator that is able to safely dispose of a wide range of medical and clinical waste including, pharmaceutical, biological and high moisture materials.

A compact medical incinerator the MP-300 includes its secondary chamber within its thick steel outer-shell, combined with 180mm of advanced insulation ensures that the MP-300 delivers outstanding results whilst being completely safe to operate compared to inferior machines which lose heat through the process.

Highly efficient in operation the MP-300 medical incinerator requires up to 40% less fuel to operate due to its advanced construction and insulation including a triple-layered brick-based refractory made up of a thick insulation board, insulation brick a followed by an Alumina Infused outer layer of Thermal bricks that reflect the heat back into the chamber whilst maintaining the heat throughout the process.

Hot Hearth Medical Incinerator

The MP-300 Medical Incinerator benefits from a Hot Hearth system which directs the heat underneath the primary chamber delivering 360° heating. Removing any cool spots and enabling the destruction of high moisture organic waste safely.

A front-loading medical incinerator can safely be reloaded through the incineration process to enable the disposal of higher amounts of medical waste than a top-loading alternative.

The MP-300 machine is equipped with a 0.76m³ chamber. Designed to handle a wide variety of waste, it is specifically competent when dealing with Category 2, 3 and 4 types or those less than <3000Kcal and red bag waste.

MP-200 (200Kg/per day) – The MP-200 Medical Incinerator

The MP200 Medical Incinerator is one of our most popular solutions for disposing of mixed hazardous waste across developing countries. Regularly chosen by international aid agencies and government bodies for installation at small hospitals, clinics and vaccination centres.

A compact medium-sized medical incinerator that is able to safely dispose of a wide range of hospital and clinical waste including, pharmaceutical, biological and high moisture materials.

A compact medical incinerator the MP200 includes its secondary chamber within a thick steel outer-shell, combined with 180mm of advanced insulation ensure that the MP200 delivers outstanding results whilst being completely safe to operate compared to inferior machines which lose heat through the process.

Highly efficient in operation the MP200 medical incinerator requires up to 40% less fuel to operate due to its advanced construction and insulation including a triple layered brick-based refractory made up of a thick insulation board, insulation brick a followed by an Alumina Infused outer layer of Thermal bricks that reflect the heat back into the chamber whilst maintaining the heat throughout the process.

Hot Hearth Medical Incinerator

The MP200 benefits from a Hot Hearth system which direct the heat underneath the primary chamber delivering 360° heating. Removing any cool spots and enabling the destruction of high moisture organic waste safely.

A front-loading medical incinerator can safely be reloaded through the incineration process to enable the disposal of higher amounts of clinical waste than a top-loading alternative.

The MP-200 medical incinerator benefits from having a large 0.57m³ chamber.

Designed to handle a wide variety of waste, it is specifically competent when dealing with Category 2, 3 and 4 types or those less than <3000Kcal and red bag waste. Ideally suited to servicing the needs of a hospital with approximately 150-300 occupied beds per day.

MP-100 (100Kg/per day) – Addfield MP-100 Medical Incinerator

The MP-100 Medical Incinerator is one of our most popular solutions for disposing of mixed medical waste across many countries. Regularly chosen by international aid agencies and Government bodies for installation at small hospitals, clinics, research centres, private surgeries, vaccination centres and other clinical waste facilities.

A compact medium-sized medical incinerator that is able to safely dispose of a wide range of medical and clinical waste including, pharmaceutical, biological and high moisture materials.

A compact medical incinerator the MP-100 includes its secondary chamber within its thick steel outer-shell, combined with 180mm of advanced insulation ensures that the MP-100 delivers outstanding results whilst being completely safe to operate compared to inferior machines which lose heat through the process.

Highly efficient in operation the MP-100 medical incinerator requires up to 40% less fuel to operate due to its advanced construction and insulation including a triple-layered brick-based refractory made up of a thick insulation board, insulation brick a followed by an Alumina Infused outer layer of Thermal bricks that reflect the heat back into the chamber whilst maintaining the heat throughout the process.

Hot Hearth Medical Incinerator

The MP-100 Medical Incinerator benefits from a Hot Hearth system which directs the heat underneath the primary chamber delivering 360° heating. Removing any cool spots and enabling the destruction of high moisture organic waste safely.

A front-loading medical incinerator can safely be reloaded through the incineration process to enable the disposal of higher amounts of medical waste than a top-loading alternative.

The MP-100 machine is equipped with a 0.38m³ chamber.

Designed to handle a wide variety of waste, it is specifically competent when dealing with Category 2, 3 and 4 types or those less than <3000Kcal and red bag waste. Ideally suited to servicing the needs of a hospital with approximately 10-150 occupied beds per day.

C200 (200Kg/hr) – High Capacity Clinical Waste incinerator machine Addfield C200.

The C200 is one of the most popular high capacity, medical waste disposal solution in the ‘C’ range.  Designed to process low density and high energy clinical waste at a burn rate of up to 200kg/hr.

Benefiting from a large primary chamber specifically designed for loads that could contain high volumes of plastic. The cylindrical chamber with its four burners optimizes airflow and directs the heat energy directly to the heart of the waste allowing this to be incinerated in a very efficient manner.

As the C200 is capable of managing general medical waste which could contain high levels of plastic it benefits from having a large 4.3m³ primary chamber. In this instance, the primary chamber is rounded which helps to eliminate any cool spots and actively encourages the optimal circulation of energy inside the chamber. Additionally, the C200 benefits from a specially adapted floor which improves the air injection below the waste alongside having an additional air curtain above the waste this circulates the oxygen throughout the chamber this ensures a stronger burn cycle and reduces the amount of fuel required.

Delivering a consistently reliable incineration cycle through utilizing the higher energy waste, reducing the need for additional energy from underneath the floor (commonly found in hot hearth machines), as once combusted the waste acts as a fuel.

Having an optimized multi-layered refractory combustion chamber allows for multiple loading options. Manually through the front-facing full-width loading door. Viewing ports allows the operator to safely see what is happening inside the chamber during the process. This approach prevents overloading to ensure you are able to achieve optimal results from every operation. This also makes the machine very ergonomic to operate. In addition to traditional manual loading, many automatic loading options are available including Bin Tipper and Waste Hopper or Ram Charger depending upon user demands.

The advanced design and construction is perfectly accompanied by a user friendly and easy to use operation. Using the custom Addfield HMI touchscreen control panel, which enables the machine to operate on a virtual ‘One Button’ operation. The C200 comes with the additional benefit of data-logging as standard. This enables the monitoring of performance and how it reacts with your unique composition of waste to make sure that it is burning successfully.

At the end of each cycle, the remaining ash residues (typically less than 3% of the original volume) can be safely removed prior to the next load being entered and the cycle repeated once again.

The C200 has been carefully designed to deliver maximum results for Hospitals, Clinics and Research Centres that need a reliable high-capacity solution to safely dispose of potentially hazardous clinical waste of all kinds.

Operating along the same principles as all Addfield machines incorporating a primary loading chamber for incinerating the waste leading to a secondary chamber, which further processes any gasses with a two-second retention time enabling for an environmentally sustainable smoke and odour free operation. Additionally, a number of more advanced filtration systems including the Venturi wet scrubber system are available. This need for advanced filtration will depend upon the categories and nature of clinical waste that you will be using your C200 to dispose of and the final country of installation. You can discover more about your options by visiting the Filtration section of the website by clicking here.

As with all Addfield incinerators the C200 has been designed and manufactured to meet and exceed many of the world’s strictest regulations to ensure a sustainable operation for many years to come. CE certified and adhering to full EU and World Health Organisation standards. Each machine is fully manufactured in Great Britain, to an extremely high standard. Constructed from heavy gauge steelwork and a multi-layered brick-lined refractory for maximum efficiency and longevity.

C100 (100Kg/hr) – C100 High capacity clinical waste incinerator.

The C100 incinerator is the most compact, high capacity, medical waste disposal solution in the ‘C’ range.  Designed to process low density and high energy clinical waste at a burn rate of up to 100kg/hr.

Benefiting from a large primary chamber specifically designed for loads that could contain high volumes of plastic. The cylindrical chamber with its four burners optimises airflow and directs the heat energy directly to the heart of the waste allowing this to be incinerated in a very efficient manner.

As the C100 is capable of managing general medical waste which could contain high levels of plastic it benefits from having a large 3m³ primary chamber. In this instance, the primary chamber is rounded which helps to eliminate any cool spots and actively encourages the optimal circulation of energy inside the chamber reducing fuel required and incineration time.

Delivering a consistently reliable incineration cycle through utilising the higher energy waste, reducing the need for additional energy from underneath the floor (commonly found in hot hearth machines), as once combusted the waste acts as a fuel.

Having an optimized multi-layered refractory combustion chamber allows for multiple loading options. Manually through the front-facing full-width loading door. Viewing ports allows the operator to safely see what is happening inside the chamber during the process. This approach prevents overloading to ensure you are able to achieve optimal results from every operation. This also makes the machine very ergonomic to operate. In addition to traditional manual loading, many automatic loading options are available including Bin Tipper and Waste Hopper or Ram Charger depending upon user demands.

The advanced design and construction is perfectly accompanied by a user friendly and easy to use operation. Using the custom Addfield HMI touchscreen control panel, which enables the machine to operate on a virtual ‘One Button’ operation. The C100 comes with the additional benefit of data-logging as standard. This enables the monitoring of performance and how it reacts with your unique composition of waste to make sure that it is burning successfully.

At the end of each cycle, the remaining ash residues (typically less than 3% of the original volume) can be safely removed prior to the next load being entered and the cycle repeated once again.

The C100 has been carefully designed to deliver maximum results for Hospitals, Clinics and Research Centres that need a reliable high-capacity solution to safely dispose of potentially hazardous clinical waste of all kinds.

Operating along the same principles as all Addfield machines incorporating a primary loading chamber for incinerating the waste leading to a secondary chamber, which further processes any gasses with a two-second retention time enabling for an environmentally sustainable smoke and odour free operation. Additionally, a number of more advanced filtration systems including the Venturi wet scrubber system are available. This need for advanced filtration will depend upon the categories and nature of clinical waste that you will be using your C100 to dispose of and the final country of installation. You can discover more about your options by visiting the Filtration section of the website by clicking here.

As with all Addfield incinerators the C100 has been designed and manufactured to meet and exceed many of the world’s strictest regulations to ensure a sustainable operation for many years to come. CE certified and adhering to full EU and World Health Organisation standards. Each machine is fully manufactured in Great Britain, to an extremely high standard. Constructed from heavy gauge steelwork and a multi-layered brick-lined refractory for maximum efficiency and longevity.
